Place of Origin:
Brand Name:
Certification:
Delivery Time:
Minimum Order Quantity:
Shenzhen, China
OEM or ZWBA
CE ROHS
2-8 working days
2
| Model: | ZA133YR, ZA140YR, ZA156YR, ZA215YR |
|---|---|
| Screen Size: | 13.3 inch, 14 inch, 15.6 inch, 21.5 inch |
| Configuration: | 1G+16G, 2G+16G, 4G+16G |
| CPU: | RK3128, RK3288, RK3399 |
| colour: | black, White |
Contacts：Adeline
Tel:+86 -17765298109
Fax:+86-755-28193671
| Display | Screen | 13.3 / 14 / 15.6 / 21.5 inch FULL HD IPS screen |
| Resolution | 1920×1080 | |
| Brightness | 300 cdm2 | |
| Contrast | 1000 | |
| Screen scale/Display area | 16：9/ Display area : 309×174mm | |
| Configuration | CPU | Rockchip RK3188 quad core processor, clocked 1.6G Rockchip RK3288 quad core processor, clocked 2.0G Rockchip RK3399 Dual core Cortex-A72 + Quad core Cortex-A53 CPU |
| RAM | 1GB/2GB/4GB | |
| ROM | 16GB | |
| System | Android 7.1 | |
| Network | WIFI | 802.11b/g/n |
| Ethernet | Supports connection to the RJ45 network interface | |
| Bluetooth | Bluetooth 4.0 | |
| 3G/4G | Support external 3G/4G USB dongle | |
| Jack | SD | 1×SD card slots (max support 32GB) |
| Mini USB | 1×USB OTG (through it to debug the machine, brush the system program) | |
| USB 2.0 | 3×USB 2.0 interface (support U disk, mouse, keyboard, printer etc) | |
| RJ45 | 1×RJ45 network interface | |
| Earphone | 1×3.5mm headphone jack | |
| Power | 1×4.0mm power DC jack | |
| Multi-Media | Video | Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P) |
| Audio | Support MP3, WMA, AAC and so on | |
| Picture | JPEG、JPG | |
| Other parameters | Wireless mouse keyboard | Support |
| Speaker | 2×2W speakers | |
| Camera | Standard 200W pixel camera (500W pixel camera optional) | |
| OSD language | Chinese, English, German, Korean, Russian, French, Spanish, Arabia etc OSD operations | |
| Software support | Free installation applications (maps, games, e-mail, self developing apps, etc.) | |
| Attachment | Adapter | One, specifications: 12V/2A |
| Desktop Bracket | One | |
| Remote control | Optional | |
| User’s Manual | One | |
| Theftproof cover plate | One, (can cover insert devices, such as U disk or SD card, to prevent theft) |
