Place of Origin:
Brand Name:
Certification:
Delivery Time:
Minimum Order Quantity:
Shenzhen, China
OEM or ZWBA
CE ROHS
2-8 working days
2
| Model: | ZWD1012T |
|---|---|
| Screen Size: | 10.1 inch |
| Configuration: | 2G+16G |
| CPU: | RK3288 |
| colour: | black, White |
Contacts：Adeline
Tel:+86 -17765298109
Fax:+86-755-28193671
| System | CPU | RK3288, Quad-core cortex A17 |
| RAM | 2GB | |
| Internal memory | 16GB | |
| Operation system | Android 8.1 | |
| Touch screen | 10-Point capacitive touch | |
| Display | Panel | 10.1″ LCD panel * 2 |
| Resolution | 1280*800 | |
| Display mode | Normally black | |
| Viewing angle | 85/85/85/85(L/R/U/D) | |
| Contrast ratio | 800 | |
| Luminance | 250cd/m2 | |
| Aspect Ratio | 16:10 | |
| Network | WiFi | 802.11b/g/n |
| Ethernet | 10M/100M ethernet | |
| B | BT 4.0 | |
| Interface | Card slot | TF, support up to 32GB |
| USB | USB for serial (TTL format) | |
| USB | USB host 2.0 | |
| Type-C | USB Type-C, only support OTG | |
| RJ45 | Ethernet function only | |
| Power jack | DC power input | |
| Earphone | 3.5mm earphone output | |
| Media play | Video format | MPEG-1, MPEG-2, MPEG-4, H.265, H.264, VC-1, VP8, etc., support up to 4K |
| Audio format | MP3/WMA/AAC etc. | |
| Photo | jpeg | |
| Other | Touch Screen | Standart dual display with dual touch, optional dual display with single touch |
| Microphone | Single microphone | |
| Speaker | 2*3W | |
| Camera | Standart single camera 5.0M/P, option Dual camera | |
| Working temp | 0–40 degree | |
| Certificates | CE, FCC, ROSH | |
| Language | Multi-language | |
| Accessories | Adapter | Adapter, 12V/1.5A |
| User manual | yes |
1. G-sensor function
2. Split-screen presentation
3. Production Monitoring
4. 10-Point capacitive touch
5. Strong CPU performance Quad core processor
